BRAND : PIONEER
ITEM NO.: ACTP65Q
ORIGIN : CHINA
MODEL NUMBER : ACTP65Q
FLUID : DIESEL/HVO/XTL | KEROSENE
VOLTAGE : 220V
HP : 1
WATTS : 550W
FLOW RATE : 40L/MIN
POWER : 550W
INLET/OUTLET : 1"
FLOW : 40 LPM
SPEED : 1400 RPM
MATERIAL : CAST IRON
BYPASS VALVE : YES
SELF PRIMING : YES
SEAL TYPE : LIP
MEAS : 28X28X32 CM
NET WEIGHT : 8.8 KGS
GROSS WEIGHT : 9.8 KGS
· SELF-PRIMING DIESEL FUEL TRANSFER PUMP
· ONLY SUITABLE WITH DIESEL OR BIODIESEL, KEROSENE
· PUMPING SPEED 80LTR PER MIN. 220V
· DIRECT DRIVE, SELF-PRIMING, VANE PUMPING UNITS, 1″ BSP PORTS
· SWITCH & 2M LONG MAINS CABLE. INTERNAL BYPASS
· WEATHERPROOF TO IP55 FOR OUTDOOR USE
· CONTINUOUSLY RATED MOTOR
IN THE RANGE OF DIESEL TRANSFER PUMPS, THIS ELECTRIC PUMP CONSISTS OF A BY-PASS VALVE FOR PRECISE ADJUSTMENT OF THE QUANTITY OF FLOW TRANSFERRED, WHILE DISPENSING, WITH A FLOW RATE OF UP TO 40 L/MIN. THE VANE PUMP WITH SINTERED STEEL ROTOR AND ACETAL RESIN VANES, AND THE INDUCTION MOTOR WITH ALUMINUM CASING MAKE THIS DIESEL ELECTRIC PUMP SUITABLE FOR CONTINUOUS CYCLE APPLICATIONS, REQUIRING A RELIABLE AND QUALITY PRODUCT. THE THERMAL PROTECTION PROTECTS IT IN CASE OF MOTOR OVERLOADS.
| Item Code | CHININACTP65Q |
|---|---|
| Barcode | 6295123309213 |
| Brand | PIONEER |
Install the pump securely on a stable surface and connect the inlet and outlet hoses (1" ports). Ensure the pump is connected to a 220V power supply. Switch on the unit using the built-in switch. The self-priming function allows quick startup without manual priming. Set the desired fuel quantity using the preset system, and begin dispensing. The integrated printer records transactions automatically. Monitor flow and ensure proper shutdown after use.
This diesel transfer pump is designed for efficient and controlled fuel transfer. It allows users to dispense precise amounts of diesel, kerosene, or compatible fuels while maintaining accurate records through the built-in printer system. It is ideal for managing fuel usage and distribution.
This pump combines precision, durability, and convenience. The preset and printing functionality makes it perfect for businesses that require accurate fuel tracking. Its robust construction and continuous-duty motor ensure reliable performance even in demanding environments, while safety features protect against overload and damage.
It is suitable for diesel, biodiesel (HVO/XTL), and kerosene. It should not be used with gasoline.
No, it features a self-priming system for quick and easy startup.
The pump delivers up to 40 liters per minute.
Yes, it has an IP55 weatherproof rating, making it suitable for outdoor environments.
Yes, it includes thermal protection and an internal bypass valve to prevent overload and damage.
